We offer both skid-type and trailer mounted models and our generators feature the latest advancements in emission and noise control and spill containment. With easy to operate control panels, trusted performance, fair pricing and responsive teams, our rental diesel generator solutions are your passport to success in any event, be it normal operation, backup or emergency.
Our technical expertise, reliable equipment and customer-focused teams have helped us deliver successfully on some of the most challenging projects. Our extensive fleet includes generators from various reputed manufacturers across a power rating of 15-2000 KVA. This gives customers a broad portfolio to choose for their specific needs.
Shaktiman Power was one of the earliest ‘pioneers’ of the concept of rental diesel generator in India. With over 16 years of rigorous experience under our belt, we bring unmatched expertise in installation and operation, trouble shooting, excellent knowledge of various industries and complete overview of various geographies and verticals.
Diesel Generators -Technical Specification
| Capacity | Diesel Engine | FUEL Consumption | DIEMENSION OF DG SET IN mm | Options Available | ||||
|---|---|---|---|---|---|---|---|---|
| KVA | KW | BHP | Ltrs / Hr @ 90% Load | Length | Width | Height | Weight (Kgs) | |
| 15 | 12 | 19 | 3.2 | 1500 | 900 | 1200 | 250 | Mobile / Skid / Acoustic |
| 30 | 24 | 43 | 5.5 | 1500 | 900 | 1200 | 380 | Mobile / Skid / Acoustic |
| 45 | 36 | 55 | 8 | 1500 | 900 | 1200 | 700 | Mobile / Skid / Acoustic |
| 62.5 | 50 | 76 | 12 | 1800 | 1100 | 1400 | 900 | Mobile / Skid / Acoustic |
| 82.5 | 66 | 115 | 15 | 1800 | 1100 | 1400 | 960 | Mobile / Skid / Acoustic |
| 100 | 80 | 127 | 18 | 1900 | 1200 | 1600 | 1200 | Mobile / Skid / Acoustic |
| 125 | 100 | 154 | 20 | 1900 | 1200 | 1600 | 1250 | Mobile / Skid / Acoustic |
| 160 | 128 | 205 | 30 | 2100 | 1200 | 1700 | 1800 | Mobile / Skid / Acoustic |
| 180 | 144 | 231 | 34 | 2100 | 1200 | 1700 | 1800 | Mobile / Skid / Acoustic |
| 200 | 160 | 255 | 40 | 2100 | 1200 | 1700 | 1800 | Mobile / Skid / Acoustic |
| 250 | 200 | 306 | 44 | 3300 | 1500 | 2100 | 2800 | Mobile / Skid / Acoustic |
| 320 | 256 | 380 | 58 | 3300 | 1500 | 2100 | 2800 | Mobile / Skid / Acoustic |
| 380 | 304 | 450 | 70 | 3600 | 1600 | 2100 | 3800 | Mobile / Skid / Acoustic |
| 500 | 400 | 614 | 92 | 4200 | 1800 | 2400 | 5500 | Mobile / Skid / Acoustic |
| 625 | 500 | 750 | 110 | 4200 | 1800 | 2400 | 6000 | Mobile / Skid / Acoustic |
| 750 | 600 | 890 | 140 | 4800 | 2100 | 3000 | 7200 | Mobile / Skid / Acoustic |
| 1000 | 800 | 1180 | 190 | 5600 | 2100 | 3000 | 8800 | Mobile / Skid / Acoustic |
| 1250 | 1000 | 1470 | 225 | 5600 | 2100 | 3000 | 9900 | Mobile / Skid / Acoustic |
| 1500 | 1200 | 1685 | 260 | 5600 | 2400 | 3000 | 11000 | Mobile / Skid / Acoustic |
Engines
Standard design, water cooled diesel engines, Turbocharged, 1500 rpm, Complete with
- Coupling
- Air Separator
- Low oil pressure safe trip
- Radiator/ Heat exchanger
- 12/24 V start /change
- Fuel Filterp
- Electronic Fuel Control
- Water Separator
- Lube oil filter
- PT Fuel System
- High water Temp/ Trip
Skid
Specially designed channel iron base frame fabricated, welded construction to accommodate engine and alternator with bottom drilled holes for solid / Anti vibration mounts.
Control Panel
Steel sheet cubicle, front/ back access, bottom cable entry, manual switching panel with MCCB or ACB, Voltmeter & ammeter with selector switch, KW meter, PF meter, KWH meter, Announciation.
Fuel Tank
12 – hour duty capacity tank, Floor mounting with level indicator, inlet, outlet, air vent & drain system
Batteries
1/2/4 X 12 V dry, Uncharged batteries with connecting leads
Other Optional Equipments
- Auto start on mains with load transfer
- Auto/Manual synchronizing for multi sets
- 415 V,3.3 Kv or 11 KV facility
- Weather Proof container units
- Silent units with Acoustic Enclosure
Mobile Trolley - As per special requirement of user
Alternators
Brushless, Suitable rated at 0.8PF, 415 Volt 3 Phase, 4-wir, 50 HZ, 1500 rpm, Self excited, regulatede, Auto voltage regulator +/-2.5%. Class F insulation, Complying to BS: 2613/IS:4722
